Silicon Showcase

Chip Gallery

High-resolution die photographs of integrated circuits designed and fabricated by the HIE Lab

14 fabricated chips across 5 categories

Doppler-Assisted PMCW Radar
Click to enlarge

Doppler-Assisted PMCW Radar

65nm CMOSmm-WaveRadar Systems
49–63 GHz FMCW Radar
Click to enlarge

49–63 GHz FMCW Radar

22nm CMOS49–63 GHzRadar Systems
23–27 & 69–81 GHz MIMO FMCW Radar
Click to enlarge

23–27 & 69–81 GHz MIMO FMCW Radar

65nm CMOS23–27, 69-81 GHzRadar Systems
Monostatic 50–60 GHz FMCW Radar
Click to enlarge

Monostatic 50–60 GHz FMCW Radar

65nm CMOS50–60 GHzRadar Systems
110–143 GHz PA (19 dBm Psat)
Click to enlarge

110–143 GHz PA (19 dBm Psat)

65nm CMOS110–143 GHzPower Generation & PA
Low-Noise 76–82 GHz VCO
Click to enlarge

Low-Noise 76–82 GHz VCO

65nm CMOS76–82 GHzVCOs & Oscillators
3.1–4.7 GHz Class-D VCO
Click to enlarge

3.1–4.7 GHz Class-D VCO

65nm CMOS3.1–4.7 GHzVCOs & Oscillators
174–232 GHz SiGe VCO
Click to enlarge

174–232 GHz SiGe VCO

SiGe BiCMOS174–232 GHzVCOs & Oscillators
90 GHz Efficient Oscillator
Click to enlarge

90 GHz Efficient Oscillator

CMOS90 GHzVCOs & Oscillators
0.32 THz SiGe Transmitter
Click to enlarge

0.32 THz SiGe Transmitter

SiGe BiCMOS0.32 THzSub-THz & THz Sources
0.48 THz Frequency Doubler
Click to enlarge

0.48 THz Frequency Doubler

SiGe BiCMOS0.48 THzSub-THz & THz Sources
0.92 THz SiGe Quadrupler
Click to enlarge

0.92 THz SiGe Quadrupler

SiGe BiCMOS0.92 THzSub-THz & THz Sources
4-Channel TIA for MEMS PNT
Click to enlarge

4-Channel TIA for MEMS PNT

CMOSBroadbandAnalog & Special Circuits
0.1–6 GHz Negative L Circuit
Click to enlarge

0.1–6 GHz Negative L Circuit

CMOS0.1–6 GHzAnalog & Special Circuits
